Description
Basic Info.
| Model NO. | HQZ-400L |
| Condition | New |
| Motor | Diesel Engine |
| Drill Hole Diameter | 90-300mm |
| Drill Hole Depth | 450m |
| Bit Type | Diamond Bit |
| Drilling Way | Impactor |
| Type | Crawler |
| Drill Pipe | Dia.76mm Dia.89 Dia.102 |
| Once Promotion Distance | 3000mm/6000 |
| Rotary Torque | 9000-10000 N.M |
| Weight | 8700kg |
| Drill Pipe Length | 3m |
| Drill Depth | 450m |
| Geology | Rock |
| Drill Diameter | 90-300 mm |
| Name | Crawler Pneumatic Rock Drilling Machine |
| Transport Package | Container |
| Specification | 5300*2050*2700 |
| Trademark | Hengwang |
| Origin | Shandong, China |
| HS Code | 8430691900 |
| Production Capacity | 500 Sets Per Month |
Packaging & Delivery
Package Size 540.00cm * 220.00cm * 250.00cm Package Gross Weight 8000.000kgProduct Description
Product Description
pneumatic rock drill machine /rock use down-hole drilling machine /deep hole water well drilling rig Crawler Hydraulic Quarry Blast Hole Dth Drilling Rig For Sale descriptionpneumatic dth drilling rig mainly drilling rock,connect with air compressor . it has fast drilling speed . pneumatic dth drilling rig can drill 20-30m per hour . high drilling effective .the engine it is Yuchai 85kw ,more powerful . pneumatic drilling rig it has 4 high hydraulic leg which can lifting 1.6m height can easy loading on the truck .Pneumatic drilling rig has steel crawler and rubber crawler . steel crawler mainly used in mountain area , rubber crawler mainly can protect the ground, not suitable mountain area use. Pneumatic drilling rig mast can customized max.height is 6m .normally the mast height is 3m .
Crawler Hydraulic Quarry Blast Hole Dth Drilling Rig For Sale technical parameters
| Model | HQZ260L | HQZ300L | HQZ450L |
| Total Weight(T) | 6.4T | 8 T | 8.7T |
| Dimensions(mm) | 4100*1900*2600 | 5500*1950*2780 | 5300*2050*2700 |
| Drilling Diameter(mm) | 140-300 | 140-325 | 130-400 |
| Drilling Depth(m) | 260 | 300 | 450 |
| One-time Advance Length of theDrill(mm) | 3000 | 3000/6000 | 3000/6000 |
| Walking Speed(Km/h) | 2.5 | 2.5 | 6 |
| Climbing Ability(max) | 30 | 30 | 30 |
| Min.Ground Clearance (mm) | 250 | 250 | 300 |
| Working Airpressure(Mpa) | 1.7-3.0 | 1.7-3.3 | 1.7-3.5 |
| Air Consumption(m³/min) | 17-35 | 23 | 17-35 |
| Main Power(kw) | 85kw Yuchai | 92kw Yuchai | 105 |
| Rotation(rpm) | 40-70 | 55-115 | 45-75 |
| Rotary Torque(Nm) | 7000-9000 | 8500-10000 | 9000-10000 |
pneumatic rock drill machine
Advantage :1.Diesel engine use Yuchai turbo supercharged engine.2.Walking device:walking motor with reducer ,long service life.3.Hydraulic oil pump : parallel type gear box ,Oil pump monomer separation ,enough power supply.4.Power head unit:gear box cast in one piece,two motor offer power,have big torque5. Chassis:Professional excavator chassis,big weight bearing capacity ,wide chain plate have small injur to road surface.6.lifting force :Composite arm have small volume ,long stroke.two oil cylinder lifting have big lifting forceDetail Images
Pneumatic drilling rig accessories mainly include drill rod , impactor ,drill bits ,etc .Also pneumatic drilling rig must use air compressor .
Product Application
Delivery
Pneumatic dth drilling rig delivery
Company Information:
Shandong Hengwang Group Is located in Shiqiao Industrial Park, Beihu Provincial Tourist & Resort Area, Jining city ,Shandong Province,covers an area of 40000 square meters, is a collection of pile driving machinery , driling machine and conctruction machinery design,manufacture and installation of an integrated enterprise. Our company produces the piling machinery a total of 10 major series more than 20 varieties,water well driling rig machine,Construction machinery and other hydraulic products. Widely used in civil engineering, municipal and building foundation construction of installation works. Can meet the roads, railways, Bridges, industrial and civil building, harbor wharf, the need for the basic construction of the dam seepage control and so on.
